Dispatched by Supplier– All welded frame of heavy steel for solid rigidity & permanent alignment
– Oven base is 3mm gauge steel with raised sides & back to catch spillage
– 2mm gauge steel baffle protects oven base from direct burner flame
– Solid burners, 3 x 18Mj: 1 x 12Mj
– Flame failure device and standing pilots fitted on burners
– Stainless Steel drip tray under burners to collect spillage
– Fully insulated oven – Fan forced
– Gastronorm compatible
– Vitreous enamel oven interior
– Oven base easily removable for cleaning
– Spring balanced oven door construction
– Supplied with 2 chrome plated oven racks, non tilting with rear plate guard
– Side gas bottom entry connection are standard
– Gas Connection: 3/4”BSP
– Electric Connection: 230V / 20 Amp
– Rating 68.5 Mj / 4.8 kW
– Dimensions: (WxDxH) 700 x 700 x 970 mm
– Net weight 135kg
GAS TYPE TO BE SPECIFIED AT TIME OF ORDERING
